CR07-72-2.0-S/F Hydraulic Damper
Linear damping control
Max. force: 40±2N, Max. stroke: 50mm.
Buffering has now become a very important feature for drawers. It will make your drawers more refined, more durable and gives them a longer lifetime. Coricher CR07-72-2.0-S/F blumotion drawer hydraulic adapters are perfect deceleration cylinders for slowing down the motion of drawers. They will prevent your furniture from becoming damaged by heavy impact.
Different damping types of push-in damping; pull-out damping, spring return damping, bi-directional damping can all be selected, depending on your requirements.
Coricher multi-talent linear motion dampers are used in sliding drawers, motion doors, lids and many other applications where damping is needed.
TECHNICAL DATA
Max stroke:
50mm
Tube length:
72mm
Max. force:
40±2N
Outer body diameter:
Ø7mm
Piston rod diameter:
Ø2mm
★Stable force performance:
√
Lifetime:
80,000 cycles
★Operating temperature:
-20 °C to +40 °C
Tube material:
Steel
Piston rod material:
Steel
Free-run:
No
PRODUCT DETAIL
Applications
Sliding drawers
Sliding doors
Sliding doors
