CR10-57-2.5-S/F Hydraulic Damper
Deceleration cylinders without free travel
Max. force: 130±2N, Max. stroke: 35mm.
Coricher CR10-57-2.5-S/F hydraulic damper cylinders provide motion control. They slow down the motion speeds and avoid closing impact to create a silent and safe environment. In addition, they are maintenance-free, self-contained and sealed units.
On top of our standard hydraulic damper cylinder models, we also provide you customized solution to meet your specific application requirements.
Coricher hydraulic damper cylinders are ideal for multiple applications, such as sliding drawers, motion doors, lids and more.
TECHNICAL DATA
Max stroke:
35mm
Tube length:
57mm
Max. force:
130±2N
Outer body diameter:
Ø10mm
Piston rod diameter:
Ø2.5mm
★Stable force performance:
√
Lifetime:
80,000 cycles
★Operating temperature:
-20 °C to +40 °C
Tube material:
Steel
Piston rod material:
Steel
Free-run:
No
PRODUCT DETAIL
Applications
Sliding drawers
Sliding doors
Lids
Sliding doors
Lids
