CR10-83-2.5-S/F Hydraulic Damper
Heavy sliding door deceleration technology for furniture
Max. force: 80±2N, Max. stroke: 63mm.
Deceleration cylinders are used in motion doors for speed reduction are a sign of a quality product. The Soft close hydraulic cabinet door dampers CR10-83-2.5-S/F designed and manufactured by Coricher are perfect for smooth and effective deceleration of sliding doors. They eliminate noise created by slamming.
Different damping types can be chosen depending on your requirements, such as: extension damping, compression damping, spring return damping and two-way damping.
Coricher top quality soft close hydraulic cabinet door dampers can be applied to heavy motion doors.
TECHNICAL DATA
Max stroke:
63mm
Tube length:
83mm
Max. force:
130±2N
Outer body diameter:
Ø10mm
Piston rod diameter:
Ø2.5mm
★Stable force performance:
√
Lifetime:
80,000 cycles
★Operating temperature:
-20 °C to +40 °C
Tube material:
Steel
Piston rod material:
Steel
Free-run:
No
PRODUCT DETAIL
Applications
Sliding drawers
Sliding doors
Lids
Sliding doors
Lids
